Container Deployment

Build a Docker image from the src/ directory and run it locally or deploy it to Azure Container Apps — the proxy listens on port 443 (HTTP) and exposes a health probe server on port 9000.

TL;DR

Build from src/ — the Dockerfile requires Shared/ and SimpleL7Proxy/ side-by-side; build context must be src/.

Probe paths are in the Host connection string — use Host1=host=https://api.example.com;probe=/health (not separate Probe_path1= variables).

Fastest path to Azure: (1) .azure/setup.sh (check prerequisites, choose scenario), (2) azd provision (create Container App + App Configuration + ACR), (3) deployment/AppConfiguration/deploy.sh (seed App Configuration from your config), (4) .azure/deploy.sh (build image, push to ACR, update Container App).

Container Ports

Port	Purpose
`443`	Main proxy traffic (HTTP, not HTTPS — TLS is terminated by ACA ingress)
`9000`	Health probe server — serves `/liveness`, `/readiness`, `/startup`

Note

Port 443 carries plain HTTP inside the container. TLS termination is done by the Azure Container Apps ingress or an upstream load balancer.

Deployment Workflow — From Code to Production

Full end-to-end path with automated scripts:

Step 1: Run setup and provision infrastructure

# From repo root
.azure/setup.sh

What it does:

Checks prerequisites (azd, Azure CLI)
Authenticates to Azure and selects subscription
Guides you through selecting a deployment scenario (local-with-cloud, full-cloud, secure-vnet)
Initializes AZD environment

Output: .azure/.env file with resource names and subscription ID.

Step 2: Provision Azure resources (Container App, App Configuration, ACR)

azd provision

What it does:

Creates resource group, Container App, Azure Container Registry, App Configuration store
Sets up managed identity for Container App
Configures networking based on your scenario selection
Exports deployment variables to .azure/.env for downstream scripts

Time: ~5–10 minutes.

Step 3: Seed App Configuration with proxy settings

cd deployment/AppConfiguration
cp deploy.parameters.example.sh deploy.parameters.sh
# Edit deploy.parameters.sh with your resource names
./deploy.sh

What it does:

Discovers all publishable settings from src/SimpleL7Proxy/Config/ProxyConfig.cs (marked with [ConfigOption(...)])
Reads current values from the running Container App (or falls back to local shell variables)
Seeds App Configuration with all discovered keys in both Warm (hot-reload) and Cold (restart) modes
Publishes them under prefixes Warm:* and Cold:* so you can toggle reload behavior instantly from the portal
Sets up the Warm:Sentinel key as the refresh trigger

Parameters required:

CONTAINER_APP_NAME: deployed Container App name
CONTAINER_APP_RESOURCE_GROUP: resource group containing the Container App
APPCONFIG_NAME: App Configuration store name
RESOURCE_GROUP: resource group for App Configuration (usually same as Container App)
LOCATION: Azure region

Output: All settings now visible in Azure Portal App Configuration > Configuration Explorer; operators can modify Warm settings without restarting.

Step 4: Build, push image, and update Container App

.azure/deploy.sh

What it does:

Extracts Docker image name and version from src/SimpleL7Proxy/Constants.cs
Logs in to ACR (from AZD environment)
Builds Docker image from src/ directory (correct context)
Pushes image to ACR with version tags (e.g., simple-l7-proxy:1.0.0, simple-l7-proxy:latest)
Optionally: applies an environment template (Standard Production, High Performance, Cost Optimized, High Availability)
Updates running Container App to the new image
Restarts container with updated configuration

Output: Container App running latest image; all Warm settings hot-reloaded within ~30 seconds; Cold settings require a second restart.

Workflow Summary (for quick reference)

.azure/setup.sh
     ↓ (authenticate, select scenario)
azd provision
     ↓ (create resources)
cd deployment/AppConfiguration && ./deploy.sh
     ↓ (seed all proxy settings into App Config)
.azure/deploy.sh
     ↓ (build, push, deploy)
✅ Proxy running in Azure with App Configuration hot-reload enabled

Key takeaway: After the first deployment, you can change Warm settings in the Azure Portal without restarting; just update Warm:Sentinel to trigger a refresh cycle.

Building the Image

Rule: Use src/SimpleL7Proxy/build.sh — it handles the correct build context, version extraction from Constants.cs, ACR login, and push automatically.

export ACR=myregistry   # your ACR name, without .azurecr.io
cd src/SimpleL7Proxy
./build.sh

The script:

Reads the version from Constants.cs (VERSION = "...") and prefixes v if needed
Logs in to ACR via az acr login
Runs docker build from src/ (the correct context that includes Shared/)
Pushes $ACR.azurecr.io/myproxy:<version> to ACR
Prints the PROXY_VERSION export line to paste into deploy.parameters.sh

Note

ACR can also be set in deployment/proxy-with-sidecar/deploy.parameters.sh — the script sources it automatically if that file exists.

Updating after a code change

# 1. Bump the version in Constants.cs if needed
#    VERSION = "2.x.x"

# 2. Rebuild and push
export ACR=myregistry
cd src/SimpleL7Proxy
./build.sh

# 3. Update the running Container App to the new image
#    (the script prints the exact version — use it below)
az containerapp update \
  --name $ACANAME \
  --resource-group $GROUP \
  --image $ACR.azurecr.io/myproxy:<version>

Tip

If you deployed with AZD, run .azure/deploy.sh instead of az containerapp update — it reads the version and environment from azd env get-values automatically.

Manual build (without the script)

Only needed if you are not using the sidecar deployment or want a custom image name:

# Must run from src/ — Dockerfile references Shared/ at the same level
cd src
docker build -t simplel7proxy:latest -f SimpleL7Proxy/Dockerfile .

Warning

Running docker build from the repository root (not src/) will fail — COPY Shared/ will not resolve.

Building without Docker (Remote ACR Build)

If Docker is not available locally (corporate restrictions, CI/CD runners, etc.), build directly in Azure Container Registry:

# From repo root
export ACR=myregistry  # Your ACR name, without .azurecr.io
export VERSION=v2.2.11 # Or read from Constants.cs

az acr build
--registry $ACR
--image simple-l7-proxy:$VERSION
--file src/SimpleL7Proxy/Dockerfile
src

Running Locally with Docker

Minimal run

docker run -p 8000:443 \
  -e "Host1=host=https://api.example.com;probe=/health" \
  -e "Timeout=2000" \
  -e "Workers=10" \
  simplel7proxy:latest

Using an environment file

Create .env:

Host1=host=https://api1.example.com;probe=/health
Host2=host=https://api2.example.com;probe=/health
Workers=20
MaxQueueLength=1000
Timeout=5000
APPINSIGHTS_CONNECTIONSTRING=your-connection-string

docker run -p 8000:443 --env-file .env simplel7proxy:latest

Docker Compose

services:
  proxy:
    build:
      context: ./src
      dockerfile: SimpleL7Proxy/Dockerfile
    ports:
      - "8000:443"
    environment:
      - Host1=host=https://api1.example.com;probe=/health
      - Host2=host=https://api2.example.com;probe=/health
      - Workers=20
      - MaxQueueLength=1000
    restart: unless-stopped
    healthcheck:
      test: ["CMD", "curl", "-f", "http://localhost:9000/liveness"]
      interval: 30s
      timeout: 10s
      retries: 3

docker compose up -d

Tip

Troubleshooting: Health check failures using port 443 will always fail — the probe server runs on port 9000. Use http://localhost:9000/liveness.

Deploying to Azure Container Apps with AZD

This is the recommended path for provisioning all required Azure resources (ACR, Container Apps environment, managed identity) in one step.

Prerequisites

Azure CLI
Azure Developer CLI (azd)
Docker (optional; only needed for local image builds)
For no-Docker environments, use the remote ACR build workflow in Building without Docker (Remote ACR Build)

Step 1 — Setup

Linux/macOS

chmod +x ./.azure/setup.sh
./.azure/setup.sh

Windows

.\.azure\setup.ps1

The setup script asks for:

Deployment scenario — choose one:
- local-proxy-public-apim — proxy runs locally, backends on public APIM
- aca-proxy-public-apim — proxy deployed as ACA, backends on public APIM
- vnet-proxy-deployment — proxy inside a VNet
Environment template (optional, see table below)

Step 2 — Provision

azd provision

Step 3 — Build and Deploy

Linux/macOS

chmod +x ./.azure/deploy.sh
./.azure/deploy.sh

Windows

.\.azure\deploy.ps1

The deploy script builds the image, pushes it to the provisioned ACR, and updates the Container App. It reads all variables from azd env get-values.

Environment Templates

Templates live in .azure/env-templates/. Apply one during setup or when prompted by deploy.sh.

Template	Best for
Standard Production	Balanced performance and cost — good default
High Performance	Maximum throughput, higher worker counts
Cost Optimized	Minimal resource usage
High Availability	Multiple backends, aggressive failover
Local Development	`dotnet run` on localhost backends
Container Development	Containerized dev/test scenarios

Deploying to Azure Container Apps Manually (CLI)

Use this path when you already have an ACR and Container Apps environment.

Step 1 — Set variables

export ACR=<your-acr-name>      # Without .azurecr.io
export GROUP=<resource-group>
export ACENV=<containerapp-env>
export ACANAME=<containerapp-name>
export LOCATION=eastus

Step 2 — Build and push

# Build from src/ directory
cd src
docker build -t $ACR.azurecr.io/simple-l7-proxy:latest -f SimpleL7Proxy/Dockerfile .
cd ..

az acr login --name $ACR
docker push $ACR.azurecr.io/simple-l7-proxy:latest

Step 3 — Create resources

az group create --name $GROUP --location $LOCATION

az containerapp env create \
  --name $ACENV \
  --resource-group $GROUP \
  --location $LOCATION

Step 4 — Deploy using YAML

A ready-to-use YAML template is at deployment/containerapp-single.yaml. Edit the placeholder values, then:

az containerapp create \
  --name $ACANAME \
  --resource-group $GROUP \
  --yaml deployment/containerapp-single.yaml

Or deploy inline with minimal settings:

az containerapp create \
  --name $ACANAME \
  --resource-group $GROUP \
  --environment $ACENV \
  --image $ACR.azurecr.io/simple-l7-proxy:latest \
  --target-port 443 \
  --ingress external \
  --registry-server $ACR.azurecr.io \
  --registry-identity system \
  --min-replicas 2 --max-replicas 10 \
  --cpu 1.0 --memory 2Gi \
  --env-vars \
    "Host1=host=https://api1.example.com;probe=/health" \
    "Host2=host=https://api2.example.com;probe=/health" \
    "Workers=20" \
    "MaxQueueLength=1000" \
    "Timeout=5000" \
    "APPINSIGHTS_CONNECTIONSTRING=your-connection-string" \
  --query properties.configuration.ingress.fqdn

Note

Use --registry-identity system (managed identity) instead of --registry-username/--registry-password to avoid storing credentials. Grant the Container App's system identity AcrPull on the registry.

Health Probe Configuration

The container exposes a built-in probe server on port 9000. Configure these in your Container App YAML:

probes:
  - type: Liveness
    httpGet:
      path: /liveness
      port: 9000
      scheme: HTTP
    initialDelaySeconds: 10
    periodSeconds: 10
    failureThreshold: 3
  - type: Readiness
    httpGet:
      path: /readiness
      port: 9000
      scheme: HTTP
    initialDelaySeconds: 5
    periodSeconds: 5
    failureThreshold: 3
  - type: Startup
    httpGet:
      path: /startup
      port: 9000
      scheme: HTTP
    initialDelaySeconds: 0
    periodSeconds: 5
    failureThreshold: 30

Sidecar Deployment (HealthProbe as separate container)

For deployments where the health probe runs as a dedicated sidecar container alongside the proxy in the same Container App revision, see SIDECAR_DEPLOYMENT.md.

Updating the Container

Rolling update

cd src
docker build -t $ACR.azurecr.io/simple-l7-proxy:v2 -f SimpleL7Proxy/Dockerfile .
docker push $ACR.azurecr.io/simple-l7-proxy:v2
cd ..

az containerapp update \
  --name $ACANAME \
  --resource-group $GROUP \
  --image $ACR.azurecr.io/simple-l7-proxy:v2

Blue-green deployment

# Send 0% traffic to the new revision initially
az containerapp revision copy \
  --name $ACANAME \
  --resource-group $GROUP \
  --image $ACR.azurecr.io/simple-l7-proxy:v2

# Gradually shift traffic
az containerapp ingress traffic set \
  --name $ACANAME --resource-group $GROUP \
  --revision-weight latest=50 previous=50

# Complete the switch
az containerapp ingress traffic set \
  --name $ACANAME --resource-group $GROUP \
  --revision-weight latest=100

Monitoring and Troubleshooting

View logs

# Stream live logs
az containerapp logs show \
  --name $ACANAME --resource-group $GROUP --follow

# Recent logs
az containerapp logs show \
  --name $ACANAME --resource-group $GROUP --tail 100

Check revision status

az containerapp revision list \
  --name $ACANAME --resource-group $GROUP -o table

Common issues

Symptom	Likely cause	Fix
Container fails to start	Missing required env var or bad image	Check `az containerapp logs show`
`503 Service Unavailable`	All circuit breakers OPEN	Verify backend hosts are reachable from inside ACA
Probe failures, container cycling	Wrong probe port	Ensure probes target port 9000, not 443
`docker build` fails with `COPY Shared/` error	Built from wrong directory	Run `docker build` from `src/`, not repo root

FilesExpand file tree

CONTAINER_DEPLOYMENT.md

Latest commit

History

CONTAINER_DEPLOYMENT.md

File metadata and controls

Container Deployment

Container Ports

Deployment Workflow — From Code to Production

Step 1: Run setup and provision infrastructure

Step 2: Provision Azure resources (Container App, App Configuration, ACR)

Step 3: Seed App Configuration with proxy settings

Step 4: Build, push image, and update Container App

Workflow Summary (for quick reference)

Building the Image

Updating after a code change

Manual build (without the script)

Building without Docker (Remote ACR Build)

Running Locally with Docker

Minimal run

Using an environment file

Docker Compose

Deploying to Azure Container Apps with AZD

Prerequisites

Step 1 — Setup

Step 2 — Provision

Step 3 — Build and Deploy

Environment Templates

Deploying to Azure Container Apps Manually (CLI)

Step 1 — Set variables

Step 2 — Build and push

Step 3 — Create resources

Step 4 — Deploy using YAML

Health Probe Configuration

Sidecar Deployment (HealthProbe as separate container)

Updating the Container

Rolling update

Blue-green deployment

Monitoring and Troubleshooting

View logs

Check revision status

Common issues

Deploy via GitHub Actions

Related Documentation
